GO Linear Actuator HV
GO Linear Actuator HV
The GO Linear Actuator, available in both standard and High Vacuum versions, offers a footprint of 67×28 mm, a travel range of 9 mm and 10 N operating lift force.
The PRECIBEO GO Linear Actuator HV is built for high vacuum environments down to 10-4 Pa. Each actuator is fitted with a vacuum side cable (PTFE coated wires in a braided metal sleeve) ended with a female D9SUB connector.
Each actuator also comes with an air side female D9SUB to ix-Industrial cable. Connect the vacuum side and air side cables to your D9SUB feedthrough, the air side ix-connector to the GO Controller, and you are ready to GO!
All products in the modular PRECIBEO GO system are compatible and are easily combined into multi-axis systems offering Smooth Continuous Motion, Fast Step & Settling Times and that are Self-Locking at Rest.
| Positioning | GO Linear Actuator HV |
|---|---|
| Travel (X) | 9 mm |
| Position Sensor | Optical Encoder |
| Sensor Resolution | 2 nm |
| Minimum Incremental Motion | 2 nm |
| Bidirectional Repeatability | +- 200nm (typ. @ full travel) |
| Motion | GO Linear Actuator HV |
| Maximum Operating Force (Push/Pull) | 10 N (min.) |
| Holding Force (When Power Is Off) | 10 N (min.) |
| Maximum Speed (At No Load) | 8 mm/s |
| Maximum Speed (At Maximum Operating Force) | 1 mm/s (min.) |
| Drive Type | GO Linear Actuator HV |
| Motor Type | Piezo Drive |
| Mechanical | GO Linear Actuator HV |
| Mechanical Interface | 9.5 mm clamping shank or M9 mounting thread |
| Size | 67x28x14 mm |
| Miscellaneous | GO Linear Actuator HV |
| Vacuum Side Cable | 0,5 m cable (+-5%) with f. D9SUB connector |
| Air Side Cable | 2 m cable (+-5%) with f. D9SUB &ix Industrial™ connectors |
| Material | Piston: Stainless Steel |
